Plan the direction on site
The reference specification describes an adjustable head but does not give a consistent model-specific aiming range. Confirm the permitted tilt and rotation on the current sample.
Commercial LED Downlights · 6499-D–6502-D Series
Adjustable Recessed LED Spotlight
A directional recessed COB spotlight family for retail and commercial interiors. the reference table lists four power and cut-out sizes plus 15° / 24° / 38° / 60° beam choices. Confirm the current fitting drawing, tilt range and photometry for the exact model.
6499-D–6502-D Series · Product configurationDirectional COB spotlight · recessed installation
Adjustable accent lighting
Direct the beam where the display needs it.
A recessed directional spotlight can highlight products, wall displays and focal areas without changing the ceiling layout. Begin with the target surface and ceiling height, then check beam, glare and cut-out together before specifying a fixture.
Four listed cut-outs
The published table lists Ø55, Ø75, Ø95 and Ø115 mm openings. Check ceiling thickness, recess depth and driver clearance against a current drawing.
Select the listed beam
The reference table lists 15°, 24°, 38° and 60° beam options. Request current photometric files for the actual COB, power and optic combination.
Product detail of the product
Specify the complete fitting
Check ceiling, light and controls as one system.
The best sample decision includes the visible trim, cut-out, recess depth, beam and driver. Check the room mock-up for glare and aiming before a multi-room roll-out.
- Send ceiling construction, thickness and required cut-out size.
- Share target object height, aiming direction and desired beam spread.
- Confirm the exact driver, dimming method, finish and market compliance in the quotation.
4Published model sizes
4Listed beam choices
Technical data
Compare the published 6499-D–6502-D models.
The values below come from the reference specification. Treat them as reference data until the current dimensioned drawing and specification are approved.
| Model | Nominal power | Ceiling cut-out | Published body size | Listed beams |
|---|---|---|---|---|
| 6499-D | 12W | Ø55 mm | Ø70 × 95 mm | 15° / 24° / 38° / 60° |
| 6500-D | 24W | Ø75 mm | Ø90 × 115 mm | 15° / 24° / 38° / 60° |
| 6501-D | 35W | Ø95 mm | Ø110 × 135 mm | 15° / 24° / 38° / 60° |
| 6502-D | 45W | Ø115 mm | Ø130 × 147 mm | 15° / 24° / 38° / 60° |
This series is presented with recessed cut-outs. Confirm the current model-specific installation drawing, opening tolerance and dimensions before ordering.
Installation referenceRecessed; verify current drawing
Housing describedDie-cast aluminum
Aiming rangeConfirm on the selected sample
Controls and driverConfirm in model-specific quotation
Product details
Review the product details.
Images are from the reference specification; compare them with the approved production sample.
Applications
Directional light for selected surfaces.
Use the family as a starting point for displays, reception zones and architectural features. Check the actual beam pattern and glare in a sample installation.
- Retail displays and feature merchandise
- Hotel and hospitality focal points
- Commercial reception and gallery-style accent zones
Concept visualization — product configuration shown for illustration.
Product FAQ
Questions before specifying?
We can confirm the exact options, compatibility and photometric data for your project configuration.
Is this a recessed or surface-mounted spotlight?
The 6499-D–6502-D reference variants use recessed ceiling cut-outs. Confirm the installation drawing for the exact model before construction.
Which ceiling openings are listed?
The reference table lists Ø55, Ø75, Ø95 and Ø115 mm for the four models. Verify the current cut-out tolerance and ceiling depth before cutting openings.
How much can the head be adjusted?
The reference specification describes an adjustable head, but the adjustment figures are not consistently tied to each model. Ask for the current drawing or test a sample at the planned aiming angle.
Can I choose the beam or dimming option?
The reference table lists 15°, 24°, 38° and 60° beams. Driver and dimming choices need confirmation for the exact power, optic and destination market.
Ready to review 6499-D–6502-D Series for your project?
Send your application, installation details, target quantity and preferred output. We’ll help confirm the most suitable sample and next step.
